Veeam B&R Components Maria Zubareva Team Leader, Veeam Technical Support
Outline
Microsoft SQL server Veeam B&R server SQL Server (<INSTANCE_NAME>) Veeam Backup Service Veeam. Backup. Reporting SQL databases Veeam Enterprise Manager Veeam Backup Enterprise Manager Service Process Driver
Veeam B&R server Veeam Backup Service Process Driver
Veeam B&R server Veeam Backup Service Veeam Backup Manager Service Process Driver
• •
• • •
Veeam B&R server Veeam Backup Console Veeam Backup Service Veeam Backup Manager Service Process Driver
Veeam B&R server Windows server/desktop Veeam Backup Console Veeam Backup Service Veeam Backup Manager Service Process Driver Veeam Backup Console
Veeam B&R server Windows server/desktop Satellite Veeam Backup Service Veeam Backup Console Veeam Backup Manager Service Process Driver Veeam Backup Console
Veeam B&R server Windows server/desktop Satellite Veeam Backup Service Veeam Backup Console Veeam Backup Manager Service Process Veeam Backup Catalog Data Service Driver Veeam Backup Console
Windows Server Veeam Backup Installer Service Process Driver
• • •
Windows Server Veeam Backup Installer Service Process Veeam Data Mover Service Driver
Windows server Veeam Backup Installer Service Veeam Data Movers (Veeam. Agents) Service Process Driver
• •
• •
Proxy Repository Installer service Data Mover service 1 notification channel read Veeam. Agent 5 data channels control channels Veeam B&R server PS HTT AP /SO Veeam Backup Manager Veeam Backup Service v. Center Veeam B&R Database write
Windows Server Veeam Backup Installer Service Veeam Data Movers (Veeam. Agents) Service Process Driver Veeam. FCT driver
Windows Server Veeam Backup Installer Service Veeam Data Movers (Veeam. Agents) Service Process Driver Veeam. FCT driver Virtual Disk Kernel-mode driver
• • •
Windows Server Veeam v. Power NFS Service Process Driver
Veeam. NFSSvc. exe • Acts as an NFSv 3 server, mountable from ESXi hosts in particular • Key component in Instant Recovery, Multi-OS FLR, Sure. Backup
Windows Server Veeam Mount Service Veeam v. Power NFS Service Process Driver
Windows Server Veeam Mount Service Veeam v. Power NFS Service Process Driver Veeam WAN Accelerator Service
Windows Server Veeam v. Power NFS Service Veeam Mount Service Veeam Remote Tape Access Service Process Driver Veeam WAN Accelerator Service
Windows server Veeam v. Power NFS Service Veeam Mount Service Veeam Remote Tape Access Service Veeam Cloud Gateway Service Process Driver Veeam WAN Accelerator Service
Veeam B&R server Windows guest VM Veeam Backup Manager Veeam Guest Helper Veeam VSS Share. Point 2010/2013 Veeam Guest Helper Control Service Process Veeam Guest Indexer Driver
• • •
• • •
Veeam B&R server Veeam Backup Manager Service Process Linux guest VM SSH Driver sshd • Indexing with mlocate • Pre-freeze scripts execution • Post-thaw scripts execution
Veeam B&R server Enterprise Manager Veeam Backup Service Process Veeam Backup Enterprise Manager Driver
Veeam B&R server Enterprise Manager Veeam Backup Service Veeam Backup Enterprise Manager Veeam Backup RESTful API Service Process Driver
Veeam B&R server Enterprise Manager Veeam Backup Service Veeam Backup Enterprise Manager Veeam Backup RESTful API Service Process v. Sphere Web Client Driver Plug-in Veeam B&R Web Client plug-in
v 8 v 9
v 8 v 9 Windows Repository Veeam B&R server ESXi/Hyper-V
Thank you
