TV Gateway Adding the Home LAN Device

TV Gateway : Adding the Home LAN Device into the pay. TV Acquisition 1 VBox Confidential

Vbox Mission Enable converge Pay. TV broadcast and new media CA protected Broadcast (Satellite/Cable) DRM protected IP stream Video VBox brings TV to any decrypts the broadcast & Today’s set-top-box device on the home network maintaining full content protection provides video to the TV

TV Gateway Broadcast TV on Any Platform Today: Set Top Box, PVR & Sling Tomorrow: Home Gateway Legacy TV Using IP STB Wired/Wireless LAN VOD Over IP (DSL/Cable) TV Channels Over DVB (Cable/Satellite) Broadband (DSL/Cable) DVB (Cable/Satellite) Residential Gateway & Network PVR

VBox TV Gateway offering: A cost-effective media server appliance for Live TV reception and streaming over IP SD/HD and EPG Receiver of DVB-S/S 2/DVB-C/DVB-T/ATSC MPEG-2/4 Connected to the existing DVB Pay. TV Headend CA/DRM integrated Media Server Appliance Same CAS, Metadata, business rules Time Shifting: multi room DVR, VOD, NVODPVOD Place Shifting: IPod, Game consol, STB, PCs Push and Reception of Data casting (DVB-IP)

VBox TV Gateway built-in Web management application for remote monitoring and control over a LAN Support SAP (Service announcement protocol) SNMP & IGMP support TV Gateway device connected to DVB-S antenna and Home router. return channel Internet connection Via Home router. Return channel can also be used for interactive TV. UI implemented Widgets platform including- subtitles/language ratings, send to a friend, etc. Copyright (c) 2009 V@Box Communications

VBox TV Gateway Illustration Broadcast & DVB-IP VOD Wire/ Wireless DRM Wire/ Wireless (Optional )Low bitrate clear wire/wireless Games consol Live TV & DVB-IP Broadcast SD&HD Home Desktop PC VOD &OTT Server TV Gateway & Mu room PVR internet 15/03/2018 Copyright (c) 2009 V@Box Communications 6

Thank You VBox Communications Ltd. 7 Shenkar st. Herzelia, Israel Tel: +972 -9 -9502821 Fax: +972 -9 -9505992 www. vboxcomm. com Copyright (c) 2009 V@Box Communications
