Think. Pad X 60/X 60 s Notebooks Disclosure ANN Oct. 17, 2006 R. Vodenicharov | © 2006 Lenovo
Think. Pad XTZR Alignment with User and Mobility X Series Primary User T Series Z Series R Series Global Travelers Simplifiers & Day Extenders Perfect Balance of Performance and Portability Stylish Notebooks for Work and Life Mainstream Features and Performance Ultimate mobility in a Positioning choice of versatile Ultraportables Increasing Mobility Lenovo Confidential | © 2006 Lenovo 2
X 60 Series - Market Segmentation Large Enterprise Priorities Ease of doing business, responsive More extensive workhorse offerings ƒ Big screens, long batt. life & docking ƒ Stability, consistency, quality ƒ Flexible configs & custom preloads ƒ Transitions, commonality, TCO & bids ƒ Connectivity centric LAN/Wireless ƒ ƒ LE X 60 Series MM X 60 Series Small Business Priorities ƒ Ability of small business customer to customize offerings, CTO direct ƒ Depth and breadth of portfolio of products at competitive price, choice ƒ Ability to better leverage e-business tools/technology ƒ Service and support coverage ƒ EOU, simplicity & Design valued SB X 60 Series Individual Priorities ƒ Targeting "Productive Individuals" ƒ Productivity & career focused ƒ Repeat purchasers, tech savvy ƒ Spend more on personal technology ƒ Require less expensive systems than LE but tuned to meet specific needs ƒ Internet focused & buy online often I X 60 Series Middle Market Priorities ƒ Prefer VAR/Reseller, external S&S ƒ Decentralized Campus/Mobile Users ƒ Ability to maintain user productivity ƒ TCO - small dedicated support staff ƒ Service & Support Coverage ƒ Small budget for e-business tools/apps Numeric Intensives analytical/numeric Download large documents ƒ Best Performance ƒ Latest PC Tech. ƒ Large form factor ƒ Experienced Users ƒ 19% of Market ƒ ƒ Primary Secondary Lenovo Confidential | © 2006 Lenovo Day Extenders Take work home (limited travel) ƒ Want one PC for home and work ƒ Heavy Internet use ƒ Need affordability ƒ Novices ƒ 11% of Market ƒ Simplifiers Travel & Simplicity Need Organization ƒ Space saving & portability ƒ Want one PC ƒ Security & Brand ƒ Novices ƒ 9% of Market Global Travelers Very mobile users In Planes & Hotels ƒ Need performance & small form factor ƒ High connectivity, access everywhere ƒ Experienced ƒ 28% of Market Status Seekers Image conscious Prestigious to compute anywhere ƒ Small & thin = cool ƒ Want advanced technology ƒ Novices ƒ 12% of Market ƒ ƒ ƒ 3
X 60 Series - Summary of Changes • Increased Performance: – New 667 MHz Intel Core 2 Duo available on some X 60 models (945 GM chipset) – New 2. 5” SATA hard drive available on X 60 Series, including new high performance hard drive 120 GB 5400 rpm – Latest Intel Napa architecture featuring processors and chipset featuring a 667 MHz front side bus, up to 4 GB of memory (3 GB of addressable memory) and Express Card via USB adapter – Vista Capable/Vista Premium-Ready logo • Increased Connectivity – – MIMO Wi. Fi available for upgrade to Think. Pad 802. 11 n Wireless LAN available through Think. Pad a/b/g and improved Intel a/b/g Wireless On/Off switch standard Embedded Wireless WAN available with service available through Cingular, Verizon, or Vodafone • New Global models available until July 2007 Lenovo Confidential | © 2006 Lenovo 4
Think. Pad X 60: The fastest Think. Pad ultraportable ever l Optimized Portability – Weight starting at 3. 15 lbs (1. 43 kg), X 60 is 12% lighter than X 32 – Footprint starting at 268 mm x 211 mm – Ultrasmall footprint with a full-sized keyboard is 7% smaller than X 32 – Maximum battery life improved by as much as 33%: as long as 7. 8 hrs with standard 8 -cell High Capacity battery, up to 10. 7 hrs by adding X 60 Extended Life battery. l Optimized Features – – – Core 2 Duo for faster computing MIMO – Mulitple In/Multiple Out for improved range and throughput Access Connections 4. 2 for easy connectivity management Connect remotely with Integrated Wireless Wide-Area Networking Options PC Card and Express. Card (34 mm Express. Card via adapter)* Save your data with the Active Protection System, Think. Pad Shock Mounted Hard Drive and unique Think. Pad X Series design Core Technology • New Intel Core 2 Duo • >20% performance gain projected over Napa platforms • L 2 cache doubled to 4 MB • Intel 945 GM Chipset • Multi-Threading, 65 nm process • New high-speed, higher capacity SATA HDDs, up to 100 GB 7200 rpm and 120 GB 5400 rpm • Up to 4 GB of PC 2 -5300 DDR 2 667 MHz memory; (3 GB addressable) • Up to 128 MB of shared Intel Graphics Media Accelerator 950 • Connect Remotely with Integrated Wireless Wide-Area Networking Options • Six Connectivity options: Modem, GB Ethernet, IR, Bluetooth, WLAN with optional MIMO* card antenna with 2 x 2 or 2 x 3 configuration, WWAN Image not Final The Think. Pad Advantage • More Reliable –Shock-Mounted Hard Drive –Active Protection System –Light metal alloy covers and “floating” planar • More Secure –Integrated fingerprint reader –Client Security Solution • Easier to Use and Manage –Integrated WWAN –Away Manager –Think. Light –All day computing *Schedule pending Lenovo Confidential | © 2006 Lenovo 9
Think. Pad X 60 s: The ultimate ultraportable experience l Optimized Portability – Weight starting at under 2. 7 lbs (1. 22 kg), X 60 s is lighter than X 41 – Footprint starting at 268 mm x 211 mm – Ultrasmall footprint with a full-sized keyboard – Maximum battery life improved by as much as 37%: as long as 8. 5 hrs with standard 8 -cell High Capacity battery, up to 11. 0 hrs by adding X 60 Series Extended Life battery l Optimized Features – – MIMO – Mulitple In/Multiple Out for improved range and throughput Access Connections 4. 2 for easy connectivity management Connect remotely with Integrated Wireless Wide-Area Networking Options 12. 1” Ultra. Light XGA display: 25% lighter and up to 20% brighter than a standard 12. 1” XGA display – PC Card and Express. Card (34 mm Express. Card via adapter)* – Save your data with the Active Protection System and Think. Pad Shock Mounted Hard Drive and unique Think. Pad X Series design Core Technology • Intel 945 GM Chipset • Multi-Threading, 65 nm process • New high-speed, higher capacity SATA HDDs, up to 100 GB 7200 rpm or 120 GB 5400 rpm • Up to 2 GB of PC 2 -5300 DDR 2 667 MHz memory; up to 3 GB of PC 2 -4200 DDR 2 533 MHz addressable memory • Up to 128 MB of shared Intel Graphics Media Accelerator 950 • Connect Remotely with Integrated Wireless Wide-Area Networking Options • Six Connectivity options: Modem, GB Ethernet, IR, Bluetooth, WLAN with optional MIMO card antenna with 2 x 2 or 2 x 3 configuration, WWAN Image not Final The Think. Pad Advantage • More Reliable –Shock-Mounted Hard Drive –Active Protection System –Light metal alloy covers and “floating” planar • More Secure –Integrated fingerprint reader –Client Security Solution • Easier to Use and Manage –Integrated WWAN –Away Manager –Think. Light –All day computing *Schedule pending Lenovo Confidential | © 2006 Lenovo 10
Top Features, Functions & Benefits of X 60 Series Features Functions Benefits Intel Core 2 Duo: Intel Merom and Yonah SV processors (dual core 667 MHz FSB) New processor increases overall system performance Increased performance for customers who demand outstanding mobile performance 802. 11 n MIMO wireless with 2 x 2 and 2 x 3 available antenna configuration Greater throughput via 2 x 2 and 2 x 3 antenna enabled by MIMO card Faster wireless connectivity for improved overall productivity Embedded Wireless WAN with Cingular, Verizon, Vodafone enabled (optional) Improved range of connectivity with integrated WAN card antenna and choice of optional service provider One of six methods of connectivity available, WWAN enables widest connection area at broadband speeds Think. Vantage Access Connections 4. 2 Cingular, Verizon, Vodafone integrated utilities for WWAN, automatic WWAN to WLAN switching, Smartcard authentication, improved wireless security with CCX V 4 Convenient and Secure Wireless Networking (wireless WAN, wireless LAN and wired Ethernet) settings to help you stay connected with improved security 4 -cell Slimline (X 60 s only) 4 -cell Enhanced, and 8 -cell High Capacity batteries + Extended Life battery Up to 11. 0 hours of battery life with X 60 Series, when using both 8 -cell High Capacity (8 hours alone) and Extended Life batteries All-day computing via standard system battery. Variety of form factor batteries offers a choice of portability vs. battery life New thin, ultralight design X 60 s and X 60 thin as 0. 79” (20 mm) X 60 s as light as 1. 22 kg, lighter than X 41 X 60 as light as 1. 43 kg, 12% lighter than X 32 Ultraportability allows users to use their PC anywhere they travel, increasing their productivity New X 60 s 12. 1” Ultra. Light XGA panel 25% lighter and up to 20% brighter than a standard 12. 1” XGA panel Better visibility in a lighter form factor for mobile travelers Fingerprint reader integrated with Client Security Solution Allows users to authenticate using their fingerprints Easy to use, high security features that help user easily comply with security policies Think. Pad Active Protection System, Think. Pad Shock-mounted HDD, Think. Pad X Series design, Rescue & Recovery Protection of key system components Suite of self-recovery tools Shock-mounted HDD, unique design of top/bottom covers and APS help protect your system and data from loss or corruption due to physical damage Rescue & Recovery can recover your data lost or corrupted data whether or not Windows will boot Lenovo Confidential | © 2006 Lenovo 15
Think. Pad X Series Intraline Comparison of Features Red = Loss in transition Blue = Gain in transition Current Think. Pad X 60 New Think. Pad X 60 Current Think. Pad X 60 s New Think. Pad X 60 s Up to 1. 83 GHz Intel Core Duo or 1. 67 GHz Solo SV Up to 2. 0 GHz Intel Core 2 Duo or 1. 66 GHz Solo SV Up to 1. 67 GHz LV Intel Core Duo LV or Solo ULV Up to 1. 83 GHz LV Intel Core 2 Duo LV or Solo 1. 66 GHz ULV Mini. PCIe Intel Golan 802. 11 a/b/g, Think. Pad 802. 11 a/b/g Intel Golan 802. 11 a/b/g, Think. Pad 802. 11 n MIMO Chipset / FSB 945 GM / 667 MHz LV 945 GM / 533 MHz ULV Graphics Up to 128 MB shared Intel Graphics Media Accelerator 950 Panel 12. 1” XGA TFT (150 nit) or 12. 1” Ultra. Light XGA TFT (180 nit) Hard Drive Up to 100 GB 7200 rpm (2. 5” SATA) and 120 GB 5400 rpm (2. 5” SATA) Up to 60 GB 4200 rpm (1. 8” PATA) Up to 100 GB 7200 rpm (2. 5” SATA) and 120 GM 5400 rpm (2. 5” SATA) System Memory /Max Open / 4 GB (3 GB addressable) Memory Type / Speed Up to 2 GBPC 2 -5300 / 667 MHz Up to 3 GB PC 2 -4200 / 533 MHz Up to 2 GBPC 2 -5300 / 667 MHz Up to 4 GB PC 2 -4200 / 533 MHz 3 – USB 2. 0, VGA, Infrared, 1394, Headphone, Microphone Processor System Ports 3 – USB 2. 0, VGA, Infrared, 1394, Headphone, Microphone Card Slots 1 Type I / II PC Card slot with EC 34 via adapter, * 1 Secure Digital card slot 1 Type I / II PC Card slot with EC 34 via adapter, 1 Secure Digital card slot Battery / Battery Life 4 -cell Enchanced Capacity Li-Ion or 8 -cell High Capacity Li-Ion / 3: 55 to 7: 51 hours 1. 43 kg (3. 15 lbs) Travel Weight / 268 mm x 211 mm x 20 – 35 mm Dimensions Lenovo Confidential | © 2006 Lenovo (10. 5” x 8. 3” x. 79 -1. 39”) 4 -cell Enchanced Capacity Li-Ion or 8 -cell High Capacity Li-Ion / 3: 55 to 7: 51 hours 1. 43 kg (3. 15 lbs) 268 mm x 211 mm x 20 – 35 mm (10. 5” x 8. 3” x. 79 -1. 39”) 1 Type I / II PC Card slot with EC 34 via adapter, * 1 Secure Digital card slot 4 -cell Slim Line, 4 -cell Enhanced Capacity, or 8 -cell High Capacity Li-Ion / 3: 00 to 8: 00 hours 1. 22 kg (2. 69 lbs) [1. 15 kg/2. 5 lbs - JP] 268 mm x 211 mm x 20 – 27 mm 1 Type I / II PC Card slot with EC 34 via adapter, 1 Secure Digital card slot 4 -cell Prismaticl, 4 -cell Cylindrical, or 8 -cell High Capacity Li-Ion / 3: 20 to 8: 30 hours 1. 22 kg (2. 69 lbs) [1. 15 kg/2. 5 lbs JP] 268 mm x 211 mm x 20 – 27 mm 16
Desktop Expansion and Power Adapter Transition X Series POWER DOCKING POWER X 3 Ultra. Base X 4 Dock 56 W 72 W X 6 Ultra. Base 65 W 90 W X 30 Series only T Series Dock II* Mini Dock Port Replicator II 72 W Mini Dock R Series No Docking 120 W G Series No Cross Generation Compatibility DOCKING X Series T Series R Series Advanced Dock* Advanced Mini Dock Essential Port Rep 65 W** 90 W Z Series CURRENT THINKPADS * Dock has an integrated power supply. Lenovo Confidential | © 2006 Lenovo NEXT GENERATION THINKPADS ** Supports select models with integrated graphics. 27
Key Usability Features of X 60 Series • Keyboard changes – Added Windows and Application keys – Simplified Fn combinations • Number Lock • Break • System Request – Multimedia functions via Fn+ Arrow keys (blue icons on keys) • Global on/off for all radios – Positional switch located on front bezel of the system – Fn + F 5 will still provide control • Cleaner, more tactile design of navigation keys • Changes to indicator LEDs – Addition of DC-in LED allows simplified indication of power state, power source & battery capacity – WWAN LED added to follow use of WLAN LED Lenovo Confidential | © 2006 Lenovo • Port labeling – Printed icons on system side provide more visible labeling for ports – Wireless switch • Port placement – Two USB ports on same side – Moved Ethernet, modem ports to opposite sides to reduce confusion • Elimination of all high-gloss finish on inside of system – To comply with GS-Mark guidelines and avoid creation of glare points • Easy component access via Customer Replaceable Units (CRU) – Memory – Wireless – 2. 5” Hard Drive – Keyboard 29
Wireless WAN Offering Description • Embedded WAN antenna – Five-band antenna covers 800, 900, 1800, 1900 and 2100 MHz – No external card/antenna to break, lose or get stolen – Better performance, battery life and usability • Fully supported by Access Connectons 4. 2 – Automatic LAN, WWAN switching • Embedded Wireless WAN available in the following geographies: – US – – – – • Cingular GSM-based HSDPA • Verizon Ev. DO • 400 -700 kpbs and bursts to 2 mbps EMEA and AP: Vodafone GSM-based HSDPA (Think. Pad’s integrated HSDPA adapter is backward compatible to UMTS, Australia New Zealand France Germany Greece Hungary Ireland Italy Netherlands Portugal Spain Sweden UK Image not Final Lenovo Confidential | © 2006 Lenovo 30
