Technical Affairs Water Projects Department 2006 Ø

Technical Affairs Water Projects Department 2006

Ø Water Projects Department Role Ø Summary of Running Projects Ø Recently Awarded Contracts Ø Under Tendering Projects Ø Budget

Water Projects Department Role In order to help kahramaa achieve its objectives, WP role is to provide Kahramaa with design engineering and execution of all water related projects and other civil constructions such as :

1. Construction of New and Refurbishment of Water Retaining Structures e. g. 1. 1 Reservoirs (RC, steel, GRP, glass fused etc. . ) 1. 2 Tanks (RC, steel, GRP, glass fused etc. . ) 2. Construction of New, Extensions, Refurbishment of Pump Stations. 3. Construction of Primary Mains downstream the Power and Desalination Stations 4. 5. 6. Extensions and Replacement of Primary Mains Extensions and Replacement of Distribution Networks General Buildings (e. g. Warehouses, Administration Buildings Water Laboratories , . . etc)

Water projects department currently has a number of running contracts. Some contracts are newly awarded; And some others are being prepared for tendering soon. In addition New projects are frequently received from the end user (WNA) to cover the timely development in QATAR.

Summary of Running Projects

1. Ras Laffan A & B water pipelines and associated reservoirs. Total amount: QR 911, 927, 064 2. Extensions of Mains at Greater Doha, Al khor Ph I & II , Al Nassiriyah, Al Ghuairiyah and Muraikh. Total amount: QR 285, 217, 742 3. Replacement and Upgrading of Mains at Doha and Mesaieed. Total amount: QR 270, 932, 629 Grand Total Amount for Running Projects: QR 1, 468, 077, 435 Ras Laffan Pipeline & Associated Extension of Mains Rep. & Upgrad. Of Mains

Recently Awarded Contracts Water supply Upgrading Works Replacement Works

Project #: GTC 60/2005 Title Upgrading New & Old Salwa Distilate & Rising Mains Description of Works Supply and lay of DI pipes ranging in size from 400 mm. to 1400 mm. Length of Mains (Kms) 31 Contract Value in Ml. QR 93. 8 Al Jaber Engineering Co. Contractor Start Date Jan 2006 Compl. Date Jan 2007

Project #: GTC 63/2005 Title Replacement of Dist. Mains at Doha (Package 1) Description of Works Supply and lay of DI pipes ranging in size from 100 mm. to 900 mm Length of Mains (Kms) 75. 8 Contract Value in Ml. QR 99. 7 AL Waha Contracting & Trading Co. Contractor start Date Jan 2006 compl. Date Sep 2007

Project #: GTC 69/2005 Title Replacement of Water Dist. Mains at Doha & Messaieed City Description of Works Supply and lay of DI pipes ranging in size from 100 mm to 600 mm. Length of Mains (Kms) 80 Contract Value in Ml. QR 44. 2 Contractor Start Date Boom Construction Co. Feb 2006 Compl. Date Feb 2008

Project #: GTC 70/2005 Title Water Supply to Madinat Alshamal, Aljerian & Um Salal Ali Description of Works Length of Mains (Kms) Supply and lay of DI pipes ranging in size from 100 mm to 600 mm. 160 Contract Value in Ml. QR 95 Contractor HBK Co. start Date Apr 2006 Compl. Date Oct 2008

Project #: GTC 71/2005 Title Upgrading of Pumping Stations at Salwa Industrial Area & Bani Hajer Description of Works Contract Value in Ml. QR Replacement of 32 old pumps with new VFD pumps at 5 water Stations, Old Salwa, New Salwa, Airport, Salwa Indut. Area and Bani Hajir including replacement of old equipment. 132 Contractor Torishima Start Date May 2006 Compl. Date Oct 2007

Future Projects Under Tendering Reservoirs & Pump stations Pipelines Works Replacement Works

Title Description of Works Length of Mains (Kms) Title Description of Works Doha South Reservoir and Associated Pipeline 4 nos. Reservoirs and 8 pumps each of 450 liter per second at 55 meter head 35 Madinat Al Shamal RPS & Associated Pipelines One 6 MIG RC reservoir + 4 new pumps each of 125 liter per second at 40 meter head.

Title Permanent Reservoir & Pumping Station at Shahaniyah to Doha Description of Works 600 mm dia pipeline, in addition to one 6 MIGD Reservoir and New pump house including 4 New pumps Length of Mains (Kms) 11

Title Upgrading of West bay & Gharafa Water Stations Description of Works Supply and lay of DI pipes ranging in size from 400 mm to 900 mm+ Pump Stations Length of Mains (Kms) 22. 6 Title Ext. of Mains at Doha Suburbs Description of Works Supply and lay of DI pipes ranging in size from 100 mm to 900 mm. Length of Mains (Kms) 118

Title Description of Works Length of Mains (Kms) Provision of Distribution Networks at Doha & North Area (Phase 1) Supply and lay of DI pipes ranging in size from 100 mm dia. to 600 mm dia. at Doha and North Qatar 265 Provision of Distribution Networks at Doha &South Area (Phase 1) Supply and lay of DI pipes ranging in size from 100 mm to 400 mm. 107

Title Replacement of Mains at Doha (Package-3) Description of Works Supply and lay of DI pipes ranging in size from 100 mm to 900 mm. Length of Mains (Kms) 100 Title Replacement of Old Pipes at Various Locations Description of Works Supply and lay of DI pipes ranging in size from 100 mm to 400 mm. Length of Mains (Kms) 121

Title Description of Works Length of Mains (Kms) Replacement of Dist. Mains at Doha Vicinity, Wakrah & Wukair package-2 Supply and lay of DI pipes ranging in size from 100 mm to 600 mm. 138

BUDGET

Thanks Presented By: Eng. Mohamad Thani AL-Maadead Head of design Water Projects Kahramaa web site www. km. com. qa
