Ningbo Xinfeng Magnet Industry Co. , Ltd. Welcome to XF Magnetic World Certificate No Q 31080934 f Mag X www. xf-magnet. com
www. xf-magnet. com Contents Xf Mag 3 1 Profile of Company 2 Factory Facility 3 XFMag Products 4 Factory Structure
www. xf-magnet. com Xf Mag Profile of XFMAG § Specialize in manufacturing strong magnet/permanent magnet -locates in Ningbo, which is a sea port city in east China. § Established in 2002, experienced the sales turnover expansion for last 6 years. Sales amount reached 13, 000 USD in 2008 § Now total area for the factory is around 6, 000 Sq. m. with staff of 155
www. xf-magnet. com Retrospect Xf Mag 2004 2005 4 million USD 4. 5 million USD 7 million USD 2006 2008 Future 13 million USD
www. xf-magnet. com Xf Mag Sintered Nd. Fe. B Equipments
www. xf-magnet. com Xf Mag Inspection Equipments
www. xf-magnet. com Xf Mag Inspection Equipments
www. xf-magnet. com Xf Mag Products Application DC Motor Speaker Medical equipment Electronical device Magnetic Separator Application Generator
www. xf-magnet. com Xf Mag Products
www. xf-magnet. com Xf Mag Products
www. xf-magnet. com Xf Mag XFMAG Products Service Range of products relates all magnetic application field, especially in DC Motor. Provide high precision products especially in Micro-application. Professional magnet solution and technical after service.
www. xf-magnet. com Xf Mag Factory Facility Melting Jet Milling XF In-house Process Pressing Sintering Inspection
www. xf-magnet. com Xf Mag Melting The materials are exposed to mid frequency and melted in an induction furnace. Jet Milling After completion of various process steps, the ingots are pulverized into particles that are several microns in size. In order to prevent oxidation from occurring, the small particles are protected by nitrogen.
www. xf-magnet. com Xf Mag Pressing The magnetic particles are placed in a jig and a magnetic field is applied while the magnets are pressed into shape. Through this process, we achieve magnetic anisotropy.
www. xf-magnet. com Xf Mag Sintering The magnetic particles are placed ingots that have been pressed are heat treated in a sintering furnace. The density of the ingots prior to sintering is about 50% of true density but after sintering, the true density is 100%. Through this process the ingots' measurement shrink by about 70%80% and their volume is reduced by about 50%.
www. xf-magnet. com Xf Mag Inspection Basic magnetic properties are set after the sintering and aging processes are complete. Key measurements including remnant flux density, coercivity, and maximum energy product are recorded. Only those magnets that pass the inspection are sent to subsequent processes including machining and assembly
www. xf-magnet. com Xf Mag Machining Plating Machining Process Size testing Coating test Magnetization Packing CUSTOMER
www. xf-magnet. com Xf Mag Machining Due to shrinkage from the sintering process, required measurements are achieved by grinding the magnets with abrasives. Diamond abrasives are used for this process because the magnet is very hard.
www. xf-magnet. com Xf Mag Plating To best suit the environment in which they will be used, the magnets are subject to various surface treatments. Nd-Fe-B magnets are generally susceptible to rust so they are surface treated with nickel or paint.
www. xf-magnet. com Xf Mag Size testing Magnets that have been machined and plated are measured and visually inspected. To ensure the high precision, we have to test the size in order to control the tolerance. So far our normal tolerance reaches +/-0. 03
www. xf-magnet. com Xf Magnetization Magnets that have been machined and plated are measured and visually inspected. In addition, magnetic properties, corrosion and maximum energy are tested to specifications.
www. xf-magnet. com Xf Mag Packing Magnets that have passed product testing are packaged and shipped. Flux leakage shields are utilized for air shipment when required. XFmagnet products are shipped in Ningbo China and to worldwide customer manufacturing locations
www. xf-magnet. com Factory Structure Xf Mag Purchase Plant Area Finance Quolity control Sales Inspection Main Departments in XFmag
Thank you f Mag X Ningbo Xinfeng Magnet Industry Co. , Ltd Add: Lihuaqiao Village Shounan Street Yinzhou Dist Ningbo CHINA Tel: 86 -574 -88160005 Fax: 86 -574 -88160007 Email: sales@xinfengmagnet. cn / xfmagnet 01@gmail. com www. xf-magnet. com
