MOUNT 10: Company, Products and Solutions ABAKUS Distribution, a. s. Jaroslav Techl techl@abdist. cz
PRODUCT STRATEGY Hi. Bars ix. T® Management Hi. Freezer™ My. Hi. Back™ Hi. Back ix. T® • mobile user backup • ease of use • low bandwidth usage • enterprise backup and restore • Performance • ATAP • Scalability • Managability • data retention • media-management • versioning • authenticity
Hi. Back ix. T™ Scalability & Availability Architecture Central Management Backup System Backup Server Storage Resources Backup System Backup Server Backup System SAN Storage Resources
Hi. Back ix. T™ Metadata what/when/where Byte(s) Command Center Client Media Label GByte(s) Backup Info (database) Backup Info (file) File details MByte(s) Catalog (file) Catalog Data
PERFORMANCE • Real multiplexing backup/ restore Server • Highly optimized software algorithms (e. g. RLE compression, CPU and network transfer optimized) • Software architecture with minimized overhead • Asynchronous and distributed Meta Data Management
SECURITY & AVAILABILITY • Data Encryption on client („Chiper Block Chaining“, high speed – low CPU consuming algorithm) • Backup, restore and management across firewalls (few selectable ports, tunnelling of silo control protocols) • Restore verification (testing the restorability of a backup without impacting the application or the original system) • ATAP restore (Any Time, Any Place) (restore of data possible without backup database or backup server)
MANAGEABILITY • Central management for an unlimited number of systems • Seamless integration of complex pre- and post-backup operations • Powerful scheduling and / or event driven backups • Interfaces to system management frameworks (Tivoli, ITO …) • Information for billing, measurement and audit on hand
Compatibility Operating Systems Applications • all major UNIX (HP-UX, Solaris, AIX. . . ) • all major databases (Oracle. Informix, DB 2, Adabas SAPDB, MS-SQL. . . ) • Linux, Linux/S 390 • Windows (NT, W 2 K, XP) • • MS Exchange Lotus Notes SAP R/3 (BAPI certified) native interface support Libraries / Silos Devices • Storage. Tek Libraries and Silos • all OS supported devices (DLT, LTO, Magstar, STK 9940, STK 9840) • ADIC/Grau Libraries and Silos • all media changers with SCSI-2 command set (IBM, ATL, Overland, HP) • Optical Disks • (Magnetic) Disks
Hi. Freezer™ Architecture
JOBNETS
Architecture
My. Hi. Back™ concepts, features, benefits
My. Hi. Back™ Benefits Ideal Backup and Restore for Remote / Mobile Users EASY: Windows Explorer-like interface. FAST: Fast. BIT™ dramatically reduces the backup size and time, because only incremental file changes will be transferred. SECURE: Up to 448 -bit encryption with Blow. Fish for the data transmission and storage on the My. Hi. Back™ Server. CUSTOMIZABLE: Pre configurable clients, backup scheduling, backup sets, quotas, filters and more…
My. Hi. Back™ Architecture
My. Hi. Back™ - Easy to Use - Backup BACKUP 1. Select Files and Folders. 2. Click on „Backup Now“. 3. Your Backup is done!
My. Hi. Back™ - Easy to Use - Restore RESTORE 1. Select the required Date. 2. Select Files and Folders. 3. Click on „Restore Now“. 4. Choice Restore Location. 5. Your Restore is done!
My. Hi. Back™ - Fast using Fast. BIT™ Technology Benefits • Enables significant faster Remote Backup´s • Reduces Bandwidth Requirements • Reduces Network Load How does it Work Fast. BIT™ precisely identify changes that have been made to any type of file since the last backup. Only these changes will be compressed and transmitted to the My. Hi. Back™ Server. The Server combines all changes with the previous backup and form an identical copy of the current files.
My. Hi. Back™ - Secure thru Encryption • Up to 448 -bit Encryption. • 3 Types of Encryption Algorithms. • Definition of individual Encryption Keys. • Encryption of the whole transmission process and the data storage on the My. Hi. Back™ Server. • Secure transmission via Internet. • Restore CD´s, created from the individual Backup Set on the Server, are encrypted as well. • A Master-Key could be established by the Administrator on the Server. The User will be asked then by the My. Hi. Back™ client to join that key.
My. Hi. Back™ Product Highlights Summary • • • • Data Backup / Restore for Mobile Computing Designed for Small Bandwidth Environments Encrypted Communication and Data Storage Interactive and Automated Backup Modes Comprehensive Backup Scheduling Redundant File Elimination Fast. BIT™ Backup Technology Individual Storage Quota Limits Customizable Backup File Sets Accounting & Quota Management Firewall Support User Policies ATAP Restore E-Mail Notifications Dial-up Networking Support 5 User Interface Languages (EN, GE, FR, E and NL)
My. Hi. Back™ Customers Mobile Users: Remote Offices: Fast and Secure Backup ATAP. Automated Backup's on a regular base to a central Server, using the bandwidth efficient Fast. BIT™ technology. Corporate End Users: critical data, ISP’s: can offer a Reliable and efficient Backup and Restore of securing complete privacy. Based on My. Hi. Back™ Server technology, ISP’s fast and secure Backup / Restore as an Off-Site Premium Service to corporate and home users.
ARCHITECTURE 3000
Děkuji Vám za pozornost
