Modernize, Secure, and Enhance your Legacy Application for Longer Life Jim Hampton Sales Engineer Crystal Point jimh@crystalpoint. com 425 806 1141

• NED Internal Standard for host connectivity Founded 1986 Outside. View. TM Leading Desktop-to-Non. Stop Connectivity software • Data Transport Security (NSSL) Provider to NED, VISA, Master. Card

We Provide More Than Emulation Host Connectivity Data Transport Security Application Modernization

Outside. View 7. 3 Newest Enhancements • SSL for FTP (& Telnet) • Seamless Guardian/OSS • Text Editing Enhancements • 3270 E Enhanced Mode

Outside. View Enterprise Deployment One-To-Many Administration

Enterprise Administration Designed for Large or Complex Environments • • Profiles • License Pools Configuration Control • Roaming Users User Permissions • Citrix/Win Terminal Automatic Update

With SSL-secured communications, plus centrally administered controls of user environments, Outside. View Enterprise provides a complete operational solution - Sture Larssen, EDS (GM/Saab)

Outside. View WEB “Green Screen” Goes Internet

Release 1. 3 Major New Features • End-to-End Encryption – HTTPS (SSL) to Web Server – Web Server to Host Via Tunneling – Multiple Tunneling Protocols; SSL, SSH 2, Telnet • Seamless OSS/Guardian – Automatic Environment Recognition via Term. Cap and. Term. Info • Log to File / Log to Printer

Def. end-to-end encryption Continuous protection of the confidentiality and integrity of transmitted information by encrypting it at the origin and decrypting at its destination.

NSSL Product Suite 1. Secure Telnet 2. Secure FTP 3. Middleware 4. Expand 5. MQ-Series

Non. Stop Secure SHell (NSSH) NSSH/FTP: File transfer security to/from other platforms using SFTP and FTP port forwarding NSSH/Secur. SH: Enables remote SSH clients to execute commands (OSS shell or TACL) on the Non. Stop server. It also provides an SSH client for the Non. Stop server; providing command execution and full shell access to an SSH-enabled remote system, including OSS pseudo terminal support for running full screen terminal applications such as VI or EMACS.

Application Modernization Maximizing the Survivability of Maximizing the Value of Your Legacy System

• Proven, Time-tested Solutions • Supporting the Core Enterprise • Capture 75% of World’s Data • Huge Intellectual and Financial Asset

• Perceived as Primitive • Perceived as Expensive to Maintain • Need for Wider User Access • Assumed Major Cost-Effort-Risk to Replace

Remain • Easiest Option • Short Term Renew • Leverages Investment • Intermediate Term Rewrite • Reduced Leverage • Difficult Business Case Replace • Packaged Solution • Often Requires Compromises

App. View. XS provides technology to upgrade and modernize legacy applications without having to rewrite (or reprogram) in order to take advantage of current technologies.

Capabilities Web-Enable Secure Transform Extend Integrate

App. View. XS Web-Enabling • Middleware Abstraction Layer • Acts on Data Stream ‘Downstream‘ • Transparent to Host, Application • Patented On-the-fly Transformation to GUI • Global HTML Template

App. View. XS Web-Enabling Architecture Guardian OSS

Architectural Advantages Highly Deployable • • • No Application Code Changes Standard (Secure) Java Portal Thin-client (Browser-based) Access Qualified on Multiple Web Platforms Rapid SOA Implementation

Capabilities Web-Enable Secure Transform Extend Integrate

End-to-End Secure Guardian OSS App. View. XS Servlet Telnet SSL SSH 2 Web Application Server https

Capabilities Web-Enable Secure Transform Extend Integrate

Transform Patented technology - Automatic GUI Transformation - Global HTML ‘Template’

Capabilities Web-Enable Secure Transform Extend Integrate

Extend • Create “Smart” Screens – Graphical, Drag-and-Drop Studio – No Programming Required – Editable HTML • “Smart” Screens for Host Screens • “Smart” Screens as Processing Layer

Example Legacy Workflow

Example Global Template • HTML Screen Envelope • Modifiable Host Screens • Embedded • Modified • Get-to-the-Point • GUI objects

Smart Screen Development

Extended Legacy Screen becomes a Smart Screen Web Link Graphics Pushbutton Navigation Embedded Java/HTML objects and automation logic, data integration (e. g. , SQL) GUI Controls, Objects

Example

Extend Studio ‘owns’ End-user Interface • Substitute GUI objects for Host fields (Buttons, Drop-down lists, etc. ) • Integrate Web technology (Calendaring Objects, Class file, Java Scripts) • Access Web Services (Address Validation Service, Class file, Java Scripts) • Modify Workflow (Get-to-the-Point, Screen transition logic) • Integrate Multiple Data Sources (SQL, Automated Background Host access)

Extend External Calls • • Java Applet Class File HTML XML Web Links • Open any URL – Static or Dynamic • GET or POST

Customization Sets for Specific User Groups And More…. Profiles Different Experience for Different Groups

Capabilities Web-Enable Secure Transform Extend Integrate

Integrate • Java Struts Framework – “Traffic Cop” • Tightly integrate Java technology with legacy applications

• Struts Framework analyzes transactions • Dynamically routes transactions to App. View. XS-abstracted Legacy Application • or add-on Java module • or replacement Java module Transition Control Ongoing Traffic Control for Hybrid Environments

Integration Benefits Hybrid Legacy/Java Environment • Legacy application becomes engine behind modern Web/GUI interface • Legacy application extended via Java ‘bolt-ons’ • Widgets (scripts, objects, class files) • Web Services • Java Modules • Java applications • Startlingly Rapid SOA Implementation

Retained by USAF to Assist in Migrating Guardian REMIS to the GCSS-AF Java Environment Project Requirements: • First Deliverable: Web Access into REMIS • Transition to Java Environment in Granular Increments • Maintain Secure, Uninterrupted Web Access Throughout • Incremental Evolution to be Transparent

David Mc. Guire, Principal Engineer for the REMIS migration project, says this about why the Crystal Point solution was chosen, “Crystal Point's App. View. XS product enabled Northrop Grumman, and more importantly, the U. S. Air Force’s REMIS System, to deploy successfully onto the Global Combat Support System portal. App. View. XS’ Server-side solution allows for tight, efficient integration between the REMIS Web Application and the Non. Stop REMIS application. All Applet-based solutions were rejected due to security and end-user configuration issues. The built-in App. View. XS capability to customize the screens using Studio as well as script transitions from one screen to the next proved invaluable. ” “The impact of the App. View. XS product cannot be overstated. Without it, REMIS had no viable option to deploy incrementally. ”

Integration Benefits Transition to Web-Tiered Environment • Select Optimum Blend - Best of Both Worlds • Reverse the business value equation – Deliver Major Benefit (Web, GUI, Security) up front • Close Cost-Before-Benefit Gap • Interactive Java Development • Match Development to Budget Cycles • Self-sustaining Development

Integration Benefits • Incremental Implementation – Avoid “Big Bang” or “Ivory Tower” Projects – Transition Control – Increased User Feedback, Training, Acceptance • Reduce Overall Costs • Make Unwieldy Projects Manageable

Rewrite • Reduced Leverage • Difficult Business Case Integrate • High Leverage • Powerful Business Case Renew • Leverages Investment • Intermediate Term

Committed to Meeting the Evolving Needs of our Customers Host Connectivity Data Transport Security Application Modernization
