HA LONG SHIPBUILDING COMPANY Add: Gieng Day – Halong city – Quang Ninh province * Tel: +84 33 846556 * Fax: +84 33 846044
General Director Mr. Nguyen Tuan Anh Ha Long Shipbuilding Company is one of the biggest subsidiaries of Shipbuilding Industry Corporation (SBIC) specialized in ship building and repairing with qualified employees and over 40 years of developing experience and application of advanced technology and equipment in production. Several products as Bulk carriers, Oil tankers, LPG tankers, Floating docks, Container ships, Car carriers for both domestic and foreign customers have been built by the Company complying with Classification rules of VR, NK, GL, DNV and other International Conventions.
Halong Shipbuilding Company headquarter located at Gieng day ward, Halong city, adjacent to Cailan deep port, National Road no. 18, Cailan-Yen Vien railway. Company has very favorable condition of marine and land transportation.
CERTIFICATE OF BUSINESS REGISTRATION ONE MEMBER OF RESPONSIBILITY LIMITED COMPANY NO. 5700100129 MAIN BUSINESS: SHIPBUILDING & REPAIR
Capability of infrastructure and equipment n n n Company’s total premises area: 450. 000 m 2 Including head office area, 13 workshops and repairing areas Premises scheme:
Main outfitting design n There are 03 new shipbuilding systems with supplemental production line, including: 1/ Tranverse slipway: enough capacity for shipbuilding and launching up to 20. 000 T. Dimension: 240 m length x 88 m width with 23 slip trucks and concentrated control station.
n n n 2/ 55. 000 T longitudinal slipway: enough capacity for shipbuilding and launching up to 55. 000 T. Dimension: 250 m length x 36 m width Standard slope of slipway is 1: 20.
n n n 3/ 70. 000 T semi- drydock: enough capacity for shipbuilding and launching up to 100. 000 T. Dimension: 352 m length x 48 m width Standard slope of slipway is 1: 20.
Lifting system There are many various lifting equipments which comply with each slipway, storage yard, erection area as follow details: 1/ 400 T gate crane n Quantity: 01 pc n It has been assembled and moved along 70. 000 T semi-drydock with max. lifting capacity up to 400 T. n Height: 110 m n Pedestal width: 85 m
2/ 300 T gate crane n n Quantity: 01 pc It has been assembled and moved along 70. 000 T semi-drydock with max. lifting capacity up to 300 T. Height: 85 m Pedestal width: 65 m
3/ Other cranes: n n n n Gate crane Q= 40 T/10 T-32/35 M : 04 pcs Gate crane Q= 30 T : 03 pcs. Foundation crane Q= 120 T : 02 pcs Foundation crane Q= 80 T : 02 pcs Foundation crane Q = 50 T : 07 pcs Foundation crane Q= 50 T : 02 pcs And many other cranes to be arranged in workshops. . .
4/ Block truck n n 150 T block truck : 02 pcs 100 T block truck : 01 pcs Cherry picker with lifting level 15 -40 m : 12 pcs. Cargo picker 5 -10 T : 05 pcs
Automatic production line of flat section -Production line descriptions: - Magnetic crane - Beveling equipment - Transport system for flat plate welding machine - One side flat plate welding machine - Cleaning and marking equipment - Spot welding machine of transverse stiffener - Transverse stiffener welding machine - Spot welding machine of longitudinal stiffener - Section inspect and complete equipment - Transport system - Material treatment system
MAGNETIC crane
Beveling equipment
Transport system for flat plate welding machine
One side flat plate welding machine
CNC marking equipment
Spot welding machine of transverse stiffener
NUPAS CADMATIC SOFTWARE
Steel fabricating workshop Workshop : 906 m 2 Outfitting : Steel fabricating production line Capacity of production line (max. ): 3, 500 T/month
Quay 70. 000 T quay The length of the quay: 151, 82 m. The width of the quay : 20 m. The height from the surface: + 5, 50 m (chart system). The depth from the bottom: - 7, 50 m (chart system). The water area : ( R = 300 m ). The height of the water area from the bottom: -7. 5 m Capacity : 03 vessel of 70, 000 tons/year to be completely built
30. 000 T quay. The length of quay: 206 m. The width of quay: 20 m. The height from the surface: + 5, 50 m (chart system). The height from the bottom: - 6, 50 m (chart system). The water area : ( R = 300 m ) The height of the water area from the bottom: -5. 5 m Capacity: 03 vessel of 70, 000 tons/year to be completely built
Outfitting quay The length of outfitting quay : 405 m. The width of outfitting quay : 9 m. The height from the surface : 5, 50 m (chart system) The height from the bottom : 3, 50 m (chart system) Water area : ( R= 300 m ) The height of the water area from the bottom: -3. 5 m Capacity: : 03 vessel of 22, 000 tons/year to be completely built
Indraft line The length of indraft line : 2. 600 m The width of indraft line : 150 m The height of indraft bottom : -5. 50 m Capacity: satisfy depth for ship with submerged
Labor force (accounted to end of Nov. 2015) Total: 1305 persons + Direct labor: 1095 + Indirect labor: 210 + Hull engineers : 88 + Engine engineers: 45 + Electric engineers : 27 + Other engineers, bachelors of commerce, construction … : 50
Foreign Ship Owner : n n n n n Ray Shipping Limited Kanematsu Florence Shipping Densan Shipping Ofer (shipholding) Atlanska plovidba dd Orange Ocean [AUG. BOLTEN WM. MILLER'S NACHFOLGER (GMBH & CO. ) KG] Thoresen Thai Agencies Public Company Limited (“TTA”) Graig Investment Damen Shipyards Gorinchem
Construction status: Typical Products built and delivered: + 53. 000 DWT bulk carriers: 09 + 8700 DWT general cargo ship: 03 + 12. 500 DWT general cargo ship: 06 + 4900 PCTC carriers: 02 + 1730 TEU container vessel: 01 + 1800 TEU container vessel: 01 + Tugs ATD 2412 for Damen: 04 + Fishery inspection vessel: 02 + 1800 TEU container vessel: 01 + 1730 TEU container vessel: 01 + Damen Pontoon 3216: 01 n Order are being built: + Damen Roro 5612: 04 + Damen PSV 3300: 02 + Fishery inspection vessel: 02 + Fishing vessel: 01 n
Domestic Ship Owner: n n n Viet Nam National Shipping Lines (Vinalines). Viet Nam Ocean Shipping Joint Stock Company (VOSCO) TST Co. , Ltd Vinashin Lines Da Nang Shipping and Commerce Company Bien Dong Shipping Company Seagull Shipping Company Vinaship Joint Stock Company Northern Shipping Joint Stock Company (NOSCO) Dong Do Marine Joint Stock company Department of Fishery Resources
Typical products 4900 PCTC CARRIERS BUILT FOR ISRAELI CLIENTS Lmax: 189. 30 m B: 32. 26 m H: 36. 56 m T: 6. 50 m
53000 DWT BULK CARRIER BUILT FOR UK CLIENTS Lmax: 190 m B: 32. 26 m H: 17. 50 m T: 12. 60 m GT: 32. 578 GT
1800 TEU CONTAINER VESSEL Lmax: 179. 7 m B: 27. 6 m H: 15. 70 m T: 0. 9 m Max. Speed: 20. 5 knot/h 1730 TEU CONTAINER VESSEL Lmax: 184. 1 m B: 25. 30 m H: 13. 50 m T: 9. 85 m Max. speed: 19. 70 knot/h
12. 500 DWT CARGO SHIP Lmax: 136. 70 m B: 20. 20 m H: 11. 30 m T: 8. 20 m GT: 8, 280 GT 8700 DWT TIMBER SHIP Lmax: 111. 70 m B: 18. 60 m H: 9. 65 m Max. speed: 14. 00 knot/h
Damen tug 2412 Lmax: 24. 65 m B: 12. 63 m H: 4. 60 m T: 2. 0 m Repairing cruise
Fishery Inspection Vessel buit for Department of Fisheries Resources Lmax: 90. 50 m B: 14. 00 m H: 7. 00 m T: 3. 75 m
PSVP Roro 5612 L: 57. 27 m B: 12 m Depth: 3. 9 m Max. Draught: 2. 75 m PSV 3300 L: 80. 0 m B: 16. 20 m Service draft: 7. 50 m Speed: 13. 5 kn GT: 3850 GT
