H. & S. Swansons’ Tool Company PRECISION MACHINING l TOOLING l FINISHING H. & S. Swansons’ Tool Company PRECISION MACHINING l TOOLING l FINISHING

OUR CERTIFICATIONS • AS 9100: 2009 Rev. C • ISO 9001: 2008 • NADCAP OUR CERTIFICATIONS • AS 9100: 2009 Rev. C • ISO 9001: 2008 • NADCAP ACCREDITED • ITAR REGISTERED

Example of our “VERTICAL INTEGRATION” capabilities 3 Example of our “VERTICAL INTEGRATION” capabilities 3

Cast Aluminum Chassis Machined, chromated, assembled and painted in-house Cast Aluminum Chassis Machined, chromated, assembled and painted in-house

Sensor Bases hogged out of aluminum. Laser Gyro’s are mounted in them for various Sensor Bases hogged out of aluminum. Laser Gyro’s are mounted in them for various guidance systems used in military and commercial aircraft.

Various Aluminum Hog Outs Various Aluminum Hog Outs

Housings machined from steel castings Housings machined from steel castings

Electrical control housings used in military and commercial aircraft as well as the GMLRS Electrical control housings used in military and commercial aircraft as well as the GMLRS system.

Titanium nodes for the Space Station with walls of only. 010” Titanium nodes for the Space Station with walls of only. 010”

Bearing Carrier. Machined from a steel casting Bearing Carrier. Machined from a steel casting

Ground plane cover for the F-16 Radar System. Ground plane cover for the F-16 Radar System.

FLIR Housing made from a hog out for the AH-64 and RAH 66 Helicopter. FLIR Housing made from a hog out for the AH-64 and RAH 66 Helicopter.

STATOR - turned, broached, marked, balanced, vertically machined. STATOR - turned, broached, marked, balanced, vertically machined.

Aluminum Hog Out Manifold & End Cap Aluminum Hog Out Manifold & End Cap

Aluminum casting used on Jet Engines. Aluminum casting used on Jet Engines.

Manifold cap hog-out from solid Aluminum. Manifold cap hog-out from solid Aluminum.

Bolt retainer machined from 4130 steel, cad or zinc plated. Bolt retainer machined from 4130 steel, cad or zinc plated.

Manifold hogout from solid Aluminum bar. Manifold hogout from solid Aluminum bar.

Brake housing hog-out from a 7075 aluminum forging. Brake housing hog-out from a 7075 aluminum forging.

Aluminum chassis hog-out from solid plate 4” thick. Aluminum chassis hog-out from solid plate 4” thick.

Aluminum hog-out from solid Aluminum hog-out from solid

Aluminum hog-out from solid, 14” X 24” X 31/2” Aluminum hog-out from solid, 14” X 24” X 31/2”

Laser chassis hog-out from solid aluminum. Laser chassis hog-out from solid aluminum.

Laser housing machined from an aluminum investment casting. Laser housing machined from an aluminum investment casting.

Hog-out aluminum cover Hog-out aluminum cover

Laser gyro sensor blocks machined, chromated, anodized and assembled Laser gyro sensor blocks machined, chromated, anodized and assembled

Manifold hog-out from aluminum. Manifold hog-out from aluminum.

Aluminum hog-out. Aluminum hog-out.

Aluminum front panel machined, painted, assembled and marked. Aluminum front panel machined, painted, assembled and marked.

Machined aluminum, gold plated. Machined aluminum, gold plated.

Aluminum, jet engine FEDEC control chassis. Aluminum, jet engine FEDEC control chassis.

Aluminum, jet engine FADEC control chassis. Aluminum, jet engine FADEC control chassis.

Transmission plate machined from aluminum plate. Transmission plate machined from aluminum plate.

7075 aluminum hog-out for the MLRS Launcher. 7075 aluminum hog-out for the MLRS Launcher.

Aluminum heat sink cover Aluminum heat sink cover

Large aluminum investment casting, machined, painted, assembled and marked. Large aluminum investment casting, machined, painted, assembled and marked.

Piston Housing First Rough Operation Billet – 417 lbs. Piston Housing First Rough Operation Billet – 417 lbs.

Piston Housing Finished – Weight 37 lbs. Piston Housing Finished – Weight 37 lbs.

Torque Stator Tube Semi-finished Torque Stator Tube Semi-finished

Carrier With brass bushing. Finished - Painted Carrier With brass bushing. Finished - Painted

Aluminum Hog Out Finished Machined and Roller Burnished Inner Wheel Finished and Painted Aluminum Hog Out Finished Machined and Roller Burnished Inner Wheel Finished and Painted

Flexible Machining System 3 Toyoda FA 450 II Horizontal Machining centers interconnected with rail Flexible Machining System 3 Toyoda FA 450 II Horizontal Machining centers interconnected with rail guided vehicle and 16, 22” square pallets in a stacker system equipped with 200 tool magazines, 14, 000 RPM spindles, 1891 IPM rapid feed rates, Renishaw probing, through-spindle coolant, linear scales and travels of X= 3. 6”, Y=22. 6” and Z=22. 0”

Flexible Machining Cell 3 Toyoda FA 630 Horizontal Machining centers interconnected with rail guided Flexible Machining Cell 3 Toyoda FA 630 Horizontal Machining centers interconnected with rail guided vehicle and 24 24. 8” square pallets, each machine equipped with up to 190 tools, 15000 RPM spindles, 1471 IPM feed rates. Renishaw probing. 39. 4” X 33. 5” Y X 30” Z.
