Flywheel energy storages for power engineering, industry and electric transport Russian superconductor Corp. Alexander Katsay General director

Problems of energy consumers 1. Power supply outages 2. Absence of energy recovery on electric transport 3. Problems with the frequency regulation 4. There is no possibility of energy redistribution by the time of the day

Solution: Flywheel / Kinetic energy storage FES-1 (4 MJ) Mass – 800 kg Energy capacity – 1, 2 k. Wh FES allows quickly give out high power in the object network or accumulate it

Кинетический накопитель энергии НКЭ-1 (4 МДж) Параметр Значение Voltage ~ 3*380 В Current 40 А Обороты маховика Давление 4000 об/мин 2000 Па Время разгона 420 с Время торможения 360 с Выходное напряжение Выходной ток Тип мотора-генератора = 730 В 40 А асинхронный Мощность мотора генератора 22 к. Вт Energy 4 МДж (1. 1 к. Вт*часа) КПД Срок службы До 97% Более 25 лет Масса 800 кг Высота 1100 мм Diameter 1200 мм

Complex helps to maintain emergency power consumption at 5 k. W for 16 hours, or provide power to 1. 2 MW for 6 minutes (the time required to run the backup power supply). Кол-во Масс махович а ных модулей 12 Напряже Оборот ние ы питания маховик а 35 ~ 3*380 В 4000 кг об/мин Тип электр омаши ны Мощно Энерго Запасаема сть емкост я энергия электр ь омаши ны асинхр 22 *12 онный к. Вт 288 МДж 40 к. Вт/часов Высота*длина*шир ина 3600*12 000*5500 мм

Сеть Режим бесперебойного питания ИБП При отсутствии питания от сети Питание осуществляет накопительный комплекс И продолжении питания ответственного потребителя Потребитель (без перебоев) 1 345 к. Вт Потребитель (перебои до 20 сек) 525 к. Вт Дизельгенераторная установка Сглаживает скачки в сети при переключении и запуске ДГУ Потребитель (без поддержки) 380 к. Вт

Market: main consumers of FES Key FES consumers are the objects in energy systems relating to 1 and 2 categories of reliability, e. g. datacenters, clinics etc. Effective demand is 125+ million € per year (~ 25 -30% of UPS market in Russia). Main market in energy recovery is metro. Pay back of FES is less then 1 year. In Russia there at least 5000 power facilities need in electric energy supply with considerable fluctuations of power level. Growing FES market segment is the Alternative Energy.

Business model Ø The basic selling product is the complex of standard FES units with the total capacity up to 150 MJ and the power of motorgenerators from 10 to 2000 k. W Ø Service during all operation time.

Next steps We are going to start small-scale production within 6 -8 months Now: - the prototype developed and tested - LOIs from customers received - 9 patents obtained

Investment offer We are seeking around $2 M (1, 5 M€) 2013 revenue to be $3 M

Competitive advantages The Russian superconductor will make a revolution on the US flywheel market The Russian superconductor Permanent magnet based flywheel. ü ü ü 2 x cheaper 30 x more capacity 12 х more power participate in frequency regulation No self-consumption The leading US player with $60 M+ in revenue IPO 2002

Team Nurbey Gulia The Scientific FES project leader. Russian scientist and inventor in the field of energy flywheel storage, stepless mechanical drive, popularizer of science and technology. Dr. of Sci. , Professor. Alexander Katsay General director. Development and commercialization of a number of high-tech devices and technologies in the field of environment, energy and nanomaterial. The team includes experienced designers, technologists, power engineers.

Thank you for attention! Katsay Alexander www. rhsc. ru E-mail: proton@rhsc. ru Mob. +7 -916 -248 -02 -44
