ECNG 1014: Digital Electronics Combinational Circuits 1
Logic Device Classification Combinational Circuit output is a function only of the current inputs eg. , AND gates, decoders Small Scale Integration (SSI) Integrated circuit uses only a few gates (20 or less). Typically provides only basic gate functions Sequential Circuit output is a function only of the current inputs AND past inputs i. e. the circuit has memory. Eg. counters Medium Scale Integration (MSI) IC uses 20 -200 gates to provide common higher level functions such as decoding, multiplexing, counting etc. Very Large Scale Integration (VLSI) IC with over 106 transistors or more which realises the highest level of logic functionality. Examples: Pentium level processors (50 mil xsistors!), FPGAs etc. Large Scale Integration (LSI) Ics have 200 -200 K gates ( 400 K transistors) or more to realise still higher functions such as small memories and microprocessors, PLDs, CPLDs etc. Device delay (and cost) goes up with complexity 2
Design Procedure for Combinational Circuits • State the problem in combinational terms. • Determine the required inputs and outputs • Derive the truth table. • Simplify the output expressions using Boolean laws or k-maps. • Implement the output expressions with logic gates. • Design example: Implement a logic circuit that detects if an unsigned 4 -bit number is prime. 3
Combinational Logic Using MSI and LSI devices • Commercial ICs can perform complex functions using a single IC of type MSI or LSI, their characteristics are described in Logic data book (http: //www. ti. com, semiconductor logic). 4
TTL Device Number Description 7483 4 -bit adder with fast carry 7485 4 -bit magnitude comparator 74139 2 -line-to-4 -line decoder/demultiplexer 74137 3 -line-to-8 -line decoder/demultiplexer 74159 4 -line-to-16 -line decoder/demultiplexer 74145 BCD-to-Decimal encoder 74147 Priority encoder 74151 8 x 1 multiplexer 74150 16 x 1 multiplexer 74184 BCD-to-binary converter 74280 9 -bit odd/even parity generator 5
Decoders (5. 4. 1 -5. 4. 5) General decoder structure • A decoder is a MIMO device that maps an input code to a different unique output code, I. e. the mapping is 1 -to-1 • Typically n inputs, 2 n outputs 2 -to-4, 3 -to-8, 4 to-16, etc • Most common: Binary Decoder maps each nbit input to assert only 1 Also: 7 -segment and BCD decoders of 2 n outputs 6
Binary decoder applications • Microprocessor memory systems – selecting different banks of memory • Microprocessor input/output systems – selecting different devices (printer, serial, video etc) • Microprocessor instruction decoding – enabling different functional units within the u. P. • Memory chips – enabling different rows of memory depending on inputted address • Identifying or selecting various circuit options. Can also be used for logic synthesis since each output actually represents a unique minterm of the inputs……. 7
Binary 2 -to-4 decoder Enable input x = don’t care. Once Enabled, ONLY the k’th logic output (k: 0, 1, . . 2 n-1) is asserted when the input binary word satisfies: I 1 I 0 = k … the k’th minterm!! => ¡¡ Y 0 = mo, Y 1=m 1, … Yi=mi !! 8
SO… can use to synthesise all logic functions of n variables!! E. g. Realise F= X, Y(0, 3) using a 74 x 139 2 -4 decoder The 1/2 => the 74139 has TWO (independent) decoders. Only using 1 of them Bubble <=> Active low enable 0 F Y X Select inputs: B is the MSB in the select word i. e. BA Most decoders use Active Low outputs => faster 9
Complete 74 x 139 Decoder All Inputs buffered to minimise loading 10
How do we get a larger decoder? Cascade smaller ones…. Use MSB(‘s) to select one decoder (for one part of the Truth Table) b 2 b 0 b 1 Use lower SB’s to select the output DEC 0_L DEC 1_L DEC 2_L DEC 3_L Upper half of TT (b 2=0) DEC 4_L DEC 5_L DEC 6_L DEC 7_L Lower half of TT (b 2=1) The “_L “ is a standard nomenclature for an active low signal line 11
Or. . We can use an off-the-shelf device, if available 74 x 138 3 -to-8 -decoder EN = (G 1)(G 2 A)’(G 2 B)’ C is MSB 12
13
8 A 0 -13 MC 6809 u. P To all memory data pins 8 Data(8) A 0 -13 To all memory address pins 14 Address (16) Control The decoder selects only 1 of the 4 banks at a time for data bus connection. 2 -4 Address A 15, A 14 Decoder 2 R/W: Connected to Memory R/W to control data direction Y 0 Y 1 Y 2 Y 3 8 A 0 -13 16 K RAM Data Address CS Specific words are determined by the lower 14 address lines connected to the memory device’s address inputs 14
Decoder Design Work Sheet Internal Memory Address Lines Address Bit: 000016 3 FFF 16 400016 7 FFF 16 800016 BFFF 16 C 00016 FFFF 16 15 1413 1211 10 9 0 0 0 0 0 1 1 1 1 0 0 0 1 0 1 1 1 1 0 0 0 1 1 1 1 8 0 1 0 1 7 0 1 0 1 6 0 1 0 1 5 0 1 0 1 4 0 1 0 1 3 0 1 0 1 2 0 1 0 1 0 1 0 1 Bank 0: A 14=A 15=0 Bank 1: A 15=0. A 14=1 Bank 2: A 15=1. A 14=0 Bank 2: A 15=1. A 14=1 FIXED for each bank 15
Comparators • The basic function of a comparator is to compare the magnitude of two binary quantities to determine the relationship of those quantities. • In its simplest form, a comparator circuit determines whether two numbers are equal. • A 1 -bit comparator is implemented as: 16
• A complex comparator can be implemented taking into account inequality. For two numbers A and B, we will have to consider ( A = B, A < B, and A > B). • The following figure gives a block diagram of a 4 -bit comparator: A[3: 0] 4 A>B 4 -bit Comparator A=B A>B B[3: 0] 4 17
For the Output A > B to be active, we must have these conditions: - If A 3 = 1 and B 3 = 0, (A 3'B 3) then A >B - If A 3 = B 3 and A 2 = 1(condition x 3 for equality between A 3 and B 3) and A 2 = 1 and B 2 = 0, (x 3 A 2 B 2'), then A >B etc The 74 X 85 (X = LS, HC, or ALS) is a 4 -bit comparator. 18
Encoders • An n-input binary encoder is a logic circuit that, given an n-bit input word X that contains one active signal xi, generates and output word Z, which is a binary representation of i, the index of the active input signal. • Thus an encoder is the inverse of a decoder, and typically has n = 2 k input lines of X and k output lines for Z. • A four-input encoder, for instance, has n = 4 and k = 2, and maps the input combinations 1000, 0100, 0010, and 0001 onto the output combinations 00, 01, 10, and 11 respectively. 19
A Binary Encoder 20
An encoder is intended to identify a single active input signal. However there is nothing to prevent several of its X input lines from being active at the same time, because they may be driven from independent external sources. To deal with this situation, most encoders are designed as priority encoders, which have the property that when several inputs are active at the same time, the output number I that appears on Z is the index of the input line xi with the highest priority. The following figures give the block diagram and logic equations of a priority encoder. 21
Block Diagrams Logic equations 22
ECNG 1014: Digital Electronics Combinational Devices: Pt 2 Multiplexers Section 5. 7, Wakerly 23
A What? A multiplexer (mux) is a device that allows us to select one of nsets of b-bit data for transmission to its b-bit output. It is a digital switch. 24
E. g. 74151 8 input x 1 bit MUX 74 x 151 EN_L Select Inputs Data Inputs EN A B C D 0 D 1 D 2 D 3 D 4 D 5 D 6 D 7 If EN = 1 Then Y=0 Else k = val(CBA) Y=Dk Endif Y Y Y=EN mk. Dk, where mk is the k’th minterm of select word CBA. 25
E. g. 2 -input, 4 -bit-wide 74 x 157 For I=1 to 4 If G=0 Then i. Y = 0 Else If S=0 Then i. Y=i. A Else i. Y=i. B Endif Endfor 74 x 157 G S 1 A 1 B 2 A 2 B 3 A 3 B 4 A 4 B 1 Y 2 Y 3 Y 4 Y i. Y = G(S’ • i. A + S • i. B), i=12, 3, 4 26
As for decoders, can use MUXes to synthesise logic E. g. Implement F=ab’+a’d+abc’ on a 2 -1 mux Solution: With 2 inputs, D 0 and D 1, say, the MUX will have 1 select input, SEL, say. Step 1: Choose variables for direct connection to the select inputs. This can be arbitrary but note that, as in all things, the actual choice will affect the amount of work required to complete the design Let SEL = a, say Step 2: Using expression for F, which will be the MUX output, select appropriate logic functions of remaining variables to drive the MUX data inputs. This may be derived by comparison of the MUX expression and the target logic function or from the function’s truth table F= Y = SEL’D 0 + SEL D 1 => F = D 0 if SEL=0 OR F=D 1 if SEL=1 <=> D 0 = F|SEL=0 <=> D 0 = F|a=0 = d Similarly, D 1 = F|a=1 = b’+bc’ =b’+c’ a SEL d D 0 b’+c’ F Y D 1 27
E. g. Use a Kmap to realise F= WXZ’ + WX’Y + XZ on an 8 -1 MUX. Step 1: There will be 3 select inputs (why? ) SEL 0, SEL 1, SEL 2. Let: W=SEL 2, X=SEL 1, Y=SEL 0. Step 2: From the K-map determine each input as YZ D 0 = 0 D 1 = 0 a logic function of the 00 01 11 10 remaining variable (Z): 0 0 01 D 2 = Z 00 0 1 1 0 11 1 1 WX D 6 = 1 D 3 = Z D 7 = 1 D 5 = 1 10 0 D 4 = 0 0 1 1 e. g. : To determine the function to be applied to D 3 note that D 3 is selected when W=0, X=1, Y=1. Now, identify all those cells for which WXY=011. Write the logic values in these cells as a function of the remaining variable, Z. 28
On a 74151 …. . 74 x 151 Note: No logic gates required!! 0 Y X W 0 0 Z Z 0 1 1 1 EN A B C D 0 D 1 D 2 D 3 D 4 D 5 D 6 D 7 Y Y F= WXZ’ + WX’YZ + XZ Exercise: Verify that this works by referring to the operation of the 74151 MUX 29
YZ 00 01 11 10 00 0 0 01 0 11 1 Same Function on a 4 -1 MUX 1 WX 10 0 0 1 1 Y Z S 0 S 1 D 0 D 1 D 2 D 3 Y F 30
Theorem on MUX realisations: A 2 n- to-1 MUX can be used to realise ALL (n+1)-variable logic functions without the use of logic gates (save for inverters). Proof: A 2 n- to-1 MUX will have n select lines. Take any n of the variables, X 0 - Xn-1, and connect them individually to these n select lines (step 1!). For each of the 2 n- select combinations, the function value will depend only on the value of the last variable, Xn (step 2!) and could therefore assume one of the 4 possible functions of this one variable: 0, 1, Xn’. The function is therefore realised by appropriately connecting any one these 4 functions of the last variable to the data inputs. 31
MUX uses As a data selector (original purpose) Not generally used for logic realisation using MSI components but… used as the core of combinational logic in some LSI and VLSI devices such as Field Programmable Gate Arrays (FPGAs). FPGAs exploit the MUX Theorem to allow general users to implement logic functions at VLSI density at a very low cost. 32
Demultiplexers • A demultiplexer basically reverses the multiplexing function. It takes data from one line and distributes them to given number of output lines. • A demultiplexer has N = 2 k output lines, k address selection and one data line. The number of the output line active is specified by the k bits address. 33
input 1 x 2 n DEMUX 2 n outputs n-bit selections Demultiplexer 34
ECNG 1014: Digital Electronics Combinational Devices: ROMs 35
Why “ROM”? • Program storage – Boot ROM for personal computers – Complete application program storage for embedded microprocessor systems. • Actually, a ROM is a combinational circuit, basically a truth-table lookup. – Can perform any combinational logic function – Address inputs = function inputs – Data outputs (stored data) = function outputs 36
ROM Internal Structure • Internal array of (address) word and (data) bit lines • Each intersection of word and bit lines interconnected by an element that can be “programmed” to be open or short circuited • Each word line is activated from the address via decoder • Each bit line outputs a logic level corresponding to the state of the interconnection with an activated word line Memory array E. g. A ROM Modern memories use MOS transistors as interconnection elements. In this example, a fully connected transistor at the intersection of an activated word line and a bit line results in a stored 0 (actually a 1 since the bit lines are usually buffered via an inverter to the corresponding data output). A disconnected transistor results in a stored 1 (a 0 at the output). 37
Two-dimensional decoding • Accommodates large address widths in a more compact form • Uses a decoder and MUX to select bits 2 D decoding in a 2 n x 1 ROM A 2 2 n bits of storage An-1 A 0 A 1 S 0 S 1 Y D 0 38
Larger example, 32 Kx 8 ROM: Stack for word storage 215=32 K address space 39
EPROMs, EEPROMs, Flash PROMs • Programmable and erasable using floating-gate MOS transistors • More reliable than fuse based PROMs • Floating gate is isolated from rest of circuit but can be charged/discharged • When discharged, transistor can be turned on by word line • When charged transistor cannot be turned on by word line • EPROM: floating gate discharged via UV light • EEPROM/Flash PROMs: floating gate can be discharged electrically 40
Typical commercial EPROMs 41
EEPROM programming • Apply a higher voltage to force bit change – E. g. , VPP = 12 V • Various bit erase procedures – Byte-byte – Entire chip (“flash”) – One block (typically 32 K - 66 K bytes) at a time • Programming and erasing are a lot slower than reading (milliseconds vs. 10’s of nanoseconds) 42
Microprocessor EPROM application Be cool! 43 Do NOT panic!
Full featrured ROM structure (except for programming) 44
Logic-in-ROM example: 2 -4 Decoder with polarity control 45
4 x 4 multiplier example Row Starting Address XY _0 _1 _2 _3 _4 Y X Data at Address Location _5 _6 _7 _8 _9 _A _B _C _D _E _F 2*F 16=2*1510 =3010=1 E 16 Hexadecimal EPROM Listing 46
Exercise Determine all the data words stored in the 8 x 4 PROM of figure 10 -5, Wakerly 47
Exercise Determine all the data words stored at A 6 -0= 0, 5, 29, 120 in the PROM of figure 10 -7, Wakerly 48
ECNG 1014: Digital Electronics Combinational Devices: PLDs Wakerly Section 5. 3 49
Programmable Logic Arrays (PLAs) • Any combinational logic function can be realized as a sum of products. • Idea: Build a large AND-OR array with lots of inputs and product terms, and programmable connections. – n inputs • AND gates have 2 n inputs -- true and complement of each variable. – m outputs, driven by large OR gates • Each AND gate has a programmable connection to each output’s OR gate. – p AND gates where (p<<2 n= no. minterms) 50
Example: 4 x 3 PLA, 6 product terms AND Array OR Array Programming selectively breaks hardwired connections. These are all fully committed at manufacture 51
Compact representation • Actually, closer to physical layout (“wired logic”). • In this model Default output is a “ 1”. Must programme “ 0’s” 52
Some product terms I 1’. I 2’. I 3’. I 4’ I 1’. I 3. I 4 53
PLA Electrical Design Vcc • See Section 5. 3. 5 -- wired-AND logic Fuse Default HIGH Fuse intact => line can be pulled low when xsistor ON Fuse blown => line remains in default HIGH state when attempt to put xsistor ON 54
Programmable Array Logic (PALs) • PLAs share product terms. How beneficial is product sharing? – Not enough to justify the amount of programmable interconnections • PALs ==> fixed OR array – Each AND gate is permanently connected to a certain OR gate. • Example: PAL 16 L 8 55
• • 10 primary inputs 8 outputs, with 7 ANDs per output 1 AND for 3 -state enable 6 outputs (IO 1 -6)available as inputs – more inputs, at expense of outputs – two-pass logic, helper terms • Note inversion on outputs – output is complement of sumof-products – newer PALs have selectable inversion • EPROM as well as original OTP (1 -time programmable) versions available 56
Designing with PALs • Compare number of inputs and outputs of the problem with available resources in the PAL. • Write equations for each output using ABEL or VHDL. • Compile the program, determine whether minimized equations fit in the available AND terms. • If no fit, try modifying equations or providing “helper” terms. 57
