ENSV ENGINEERING SSRVICES • • History Since acquiring the existing facility assets from four private bus service providers in the mid 1970’s to form Metrobus, the maintenance and training facilities proved to be either inadequate or nonexistent. In 2000, the opportunity to acquire this 725, 524 s. f. facility provided the opportunity to provide consolidated backshop maintenance and training for both Bus and Rail. The ability to provide focused hands-on training directly affects the ability to perform necessary preventive maintenance by highly skilled personnel to maintain equipment to ensure maximum service life and maintain a state of good repair. The backshops provide the in-house capability to perform mid -life rehabilitation and replacement of components to ensure full life cycle utilization and contribute to maintaining a state of good repair. 2

ENSV CTF Layout Bus Paint & Body Shop BLDG F Safety ENGINEERING SERVICES Bus Machine Shop BLDG E Plant Maintenance Elevator/Escalator Storerooms and Shops BLDG A Training BLDG B ELE Rail OCC BLDG D Bus Maintenance Data Center Plant Maintenance BLDG C 3

ENSV ENGINEERING SERVICES • • Building A Plant Maintenance Shops and Offices: Graphics, Sheet Metal, Machine, Portable Lift Repair, Plumbing, Carpentry, Locksmith, Welding, Silk Screen Warehouse Space: Plant Maintenance and Elevators and Escalators Graphics Shop Sheet Metal Shop 4

ENSV ENGINEERING SERVICES Building A Machine Shop Portable Lift Shop Locksmith Plumbing Shop Carpentry Shop 5

ENSV ENGINEERING SERVICES • • Building B 1 st Floor: – Classrooms and Training Facilities for BUS, RAIL, and Plant Maintenance – Storage BUS, Power, and Train Control – Cardoza Trans. Tech Academy – Security Operations Center 2 nd Floor: – Audio-Visual Lab – Farecard and Faregate Training – Elevator & Escalator Operations Center – RAIL and Bus Training Facilities Bus Simulator Lab Technical Skills Shop 6

ENSV ENGINEERING SERVICES Building B Audio-Visual Lab Farecard and Gate Training Elevator and Escalator Operations Center Computer Equipped Classroom Transit Police Security Ops Center 7

ENSV ENGINEERING SERVICES • • Building C 1 st Floor: – Offices for Engineering, Human Resources, Information Technology, Rail, and Safety – Cafeteria 2 nd Floor: – Offices for Plant and Bus Maintenance – Future Bus Operations Control Center – Data Center Future Bus Operations Control Center 8

ENSV ENGINEERING SERVICES Building D • 1 st Floor: – New Rail Operations Control Center – New DATA Center – Offices, Training Rooms • 2 nd Floor – New Command Center – New Offices for Rail Operations Control and Transit Police – New Communications Room Rail Operations Control Center View From Right With Command Center Above Rail Operations Control Center View From Controller’s Console 9

ENSV ENGINEERING SERVICES Building D Command Center Communications Room Elevator/Escalator Lab 10

ENSV ENGINEERING SERVICES • Building E Bus Heavy Overhaul Shop: Steam Room, Radiator Shop, Machine Shop, Bus Graphics, Engine and Transmission Shop, Welding, Fare Box, Transmission Dynamometer, Engine Dynamomener Engine & Transmission Machine Shop Engine Dynamometer Fare Box Room Radiator Shop 11

ENSV ENGINEERING SERVICES • • Building F Open Storage (Future Bus Paint and Body Shop) Safety EMT Training Tunnel, ROW Training and Rollover Car Right-of-Way Training Tracks Emergency Response Training Tunnel Rail Car Training Rollover Train 12

ENSV ENGINEERING SERVICES Future Plans • Permanent ROCC in Building D • Permanent BOCC in Building C • Bus II CNG Paint and Body Shop in Building F 13
