2009 Critical Software S A Dependable Technologies

The genesis Mission To provide dependable and innovative technologies and engineering solutions for mission

The Innovation Cycle Knowledge intensive Less competition Lower Barriers Awareness Mid step Lower Barriers Niche Institutional Universiti es Partners Labs R&D Partners technology transfer © 2009 Critical Software S. A. IP Innovation Marketing Critical Software technology solutions services products Markets VOLUME SINERGY PARTNERSHIPS Market 3

© 2009 Critical Software S. A. Dependable Technologies For Critical Systems Space • Case

cs. Xception Automated Fault-Injection Environment Challenge § Perform intensive testing in a HW/SW system with minimal intrusiveness cost effectively § Simulate realistic executions conditions and worst failure scenarios. § Identify failures and its causes providing feedback for correction or redesign. Customer © 2009 Critical Software S. A. Solution § cs. Xception spots weak points in the system, relying on advanced debugging and performance monitoring hardware features, available in common processors, to inject faults and monitor the activation of errors and their impact on the target system Benefit § cs. Xception performs state-of-art product certification on the dependability/RAMS area. It brings in open technologies and standards to provide a professional environment for performing fault-injection based tests. 5 5

I. S. Verification & Validation Lisa. Pathfinder; Cryo. Sat and Cryo. Sat-2; GOCE; Sentinel-1 Challenge § Verify and Validate the on-board software according to the applicable standards and mission requirements Solution § Perform code inspections § Static analysis and code coverage § Profiling and metrics gathering Customer § Test design, implementation and execution § ISVV © 2009 Critical Software S. A. Benefit § Ensure that the developed software is complaint with the applicable criticality levels and the overall mission success § Critical Software best practices converted in an ESA Guide for V&V activities § 90% increase in robustness/trust of the product and ROI of about 1, 5 to 5 times 6 6

Galileo Payload Security Units Challenge § Assure Galileo´s satellites navigation safety § Develop the TM/TC onboard processing for the Galileo Payload Security Units Solution § On-board Software development according to the Galileo Software Standards (criticality level: DAL-B) Customer § Support to integration testing and validation © 2009 Critical Software S. A. § Development of the encrypted subsystem software for the 4 satellites of the In Orbit Validation phase § Implementation of DO-178 B Level A and B, Galileo software norms Benefit § High reliable software developed according to very demanding standards 7 7

Herschel / Planck RTEMS Tailoring and Qualification Challenge § Ensure the RTOS fits the on-board computer defined budget § Reduce and optimize memory footprint of the Basic SW Solution § Tailoring of the RTEMS, removing unused code and unnecessary RTEMS functions Customer § Qualification of the final result to ensure requirements fulfilment © 2009 Critical Software S. A. § Expert team deployment to support integration testing Benefit § Tailor made RTEMS for theses missions, optimized to its on-board computer and memory footprint minimized § BUG discovery and correction in RTEMS during qualification campaign and reverted to the RTEMS 8 8

Premfire Fire Combat Management and Control System Challenge § Manageable, Efficient and Safe Fire Fighting Operations; § Build a powerful and portable mission critical software system for Fire Combat and Resource Management. FOTO Solution § C&C Solution to support Fire Fighting activities § Planning, Operation Control, Decision Support and Reporting § Wireless Com (GPRS/TETRA), GNSS (GPS/EGNOS), GIS, Mobile Computing (Tablets) § System divided in three levels (Position, Mobile and C&C) with continuous exchange of geographical and alphanumeric information. Wide access to WMS/WFS – OGC / INSPIRE compliant © 2009 Critical Software S. A. § Customer Benefit § Real Time operational environment; § Expandable, Reliable; § COTS based on open source and space spin-off development. 9 9

x. Luna Demo with Exo. MADER (Exo. Mars Demonstration Rover) Challenge § Complex applications to perform tasks such as science data processing or autonomous mission planning can now be considered to be ported to an on-board system as resources increase § Develop a reliable RTEMS/Linux based kernel that can be used for both payload and avionics applications Solution Customer § RTEMS/Linux based kernel § Standard programming interfaces (e. g. , POSIX, µITRON API) § Spatial partitioning © 2009 Critical Software S. A. Benefit § Allow the integration of applications developed in Linux without extra validation/qualification effort in Space Systems without compromising the Hard Real Time critical applications § Co-existence of real and non real time tasks § New testing environment for the rover application development 10 10

Dependable Technologies For Critical Systems Science Educational Responsibility • International Year of Astronomy 2009 a. Descobre o Teu Céu b. Lunar stone visits Portugal © 2009 Critical Software S. A. • World Space Week

© 2009 Critical Software S. A. International Year of Astronomy 2009 12

World Space Week § Promote and Celebrate the 50 th Anniversary of Space © 2009 Critical Software S. A. § The 50 th anniversary of the Space Age was an unprecedented opportunity for the global space community to positively impact the public, government leaders, and students, by organizing a synchronized global celebration. 13

Contacts § Rui Melo Biscaia § Marcom Director © 2009 Critical Software S. A. § rui. m. biscaia@criticalsoftware. com San Jose Coimbra, Lisbon, Oporto Southampton www. criticalsoftware. com www. critical-software. co. uk Bucharest www. criticalsoftware. ro Sao Paulo www. criticalsoftware. com. br 14

© 2009 Critical Software S. A. Dependable Technologies For Critical Systems Back-up Slides

Critical Software, the “mothership” § Spin-off of the University of Coimbra, July 1998 § Dependable Technologies for Critical Systems § Software engineering company § Mission: to support mission and business critical solutions § Development of dual use technology: aimed at military and civil markets Coimbra, Portugal § Manufacturing, Energy, Telecom, Finance and Government § Aeronautics, Space, Defence and Transports © 2009 Critical Software S. A. § 3 Engineering Centers in Portugal Lisboa, Portugal § Coimbra, Lisbon, Porto, § Over 330 engineers § More than 30 fully allocated to R&D Porto, Portugal 16

The Group Critical § Global Vision § Subsidiaries in the US, UK, Romania, Brazil (kicking off) § Representatives in many different parts of the world: © 2009 Critical Software S. A. § South Africa, Angola, Brasil, China, India, Mozambique, . . . Southampton, UK San Jose, CA, USA Bucharest, Romania § Exports: ~70% of total turnover in 2008 Sao Paulo, Brazil Regensburg, Germany 17

Office Locations & Geographic Markets EUROPE USA © 2009 Critical Software S. A. PSAC

The Group Critical SGPS João Carreira, Dino Costa, Gonçalo Quadros New Critical Software Coimbra, Lisbon, Porto Portugal CSW Tech. Southampton, UK CSW Limited San Jose, USA CSW Romania Bucharest CSW Gmbh, Regensburg, D New Critical Software do Brasil SJC, SP Brian Luff Nuno Almeida Cristovão Bento New © 2009 Critical Software S. A. Critical Links New Jersey, USA Critical SGPS Inovcapital Change. Partners Critical Materials Guimarães, PT Critical Health Coimbra, PT Critical Manufacturing PT, DE, CN New Critical Move PT Critical SGPS Gustavo Dias Ricardo Cunha Vaz 3 leading founders 2 leading founders Júlio Viana ISQ Capital 19

Financial figures § High-growth profile (organic) Turnover M€ § 19 M€ in 2008 § Good capacity to generate wealth § EBITDA: between 10% and 22% from year one § Re-investment of all generated wealth © 2009 Critical Software S. A. § Strong investment in R&D § ~10% of turnover 2004 2005 2006 2007 2008 20

© 2009 Critical Software S. A. Customers and markets 21

Competencies Portfolio § Space Segment and Launchers flag competencies are: § Onboard Software Development § Real Time Operating Systems (RTOS) Qualification and Tailoring § Reliability Availability Maintainability and Serviceability (RAMS) § Verification and Validation services (V&V) © 2009 Critical Software S. A. § Ground Segment flag competencies are: § Mission Control Systems (SCOS-2000 Monitoring & Control system) § Mission Planning Systems § Payload Data processing § Simulation 22
