What is a Sonozaire Odor Neutralizer? n Sonozaire Odor Neutralizers are ozone generators that use oxygen from the air to produce ozone. n Ozone is a form of oxygen that oxidizes and destroys odor molecules on a molecular level. n When ozone reacts with odors it naturally breaks down to harmless moisture and carbon dioxide.
Where are Sonozaires Used? n Waste Management n Fire/Water Restoration n Dry Cleaning n Auto Detailing n Hotels/Apartments n Air Purification n Anywhere Odors Linger!
Why Use Sonozaire? In the Ozone business since 1979 n Industrial built machines with over a 15 year life span n No chemicals to buy n Quality products and friendly service n One year warranty and 30 day money back guarantee on all models n
105 A n Produces 1. 1 gm/hr of ozone n Treats Up to a 4 yard garbage container n Only 9 pounds n Standard 12 hour timer and ozone control knob
115 A n Produces 2. 2 gm/hr of ozone n Treats Up to an 8 yard garbage container n Weighs 36 pounds
330 A n Produces 4. 5 gm/hr of ozone n Treats an 8 to a 30 yard garbage container n Ideal for medium garbage containers
630 A n Produces 8. 5 gm/hr of ozone n Treats a 30 to a 50 yard garbage container n Ideal for large garbage containers
How to Install a Sonozaire to a Compactor.
1. Install Flanges Install 2. 5” hole in the container Drill a 2” Aluminum Flanges for and Hose Connection with self chute (optional) tapping screws: One on compactor One on container (optional) Loading Chute Roll-Off Container
2. Install Sonozaire Unit Mount the Sonozaire Unit on the wall at a point where the top of the unit is higher than the Flanges. Sonozaire Roll-Off Container
2” 90 Degree Elbow Hose Clamp 3. Install Elbow and Short Hose Install a 2” 90 deg Elbow with a short piece of hose and a hose clamp 2 ½” PVC Flexible Hose Sonozaire Roll-Off Container
2” Y Fitting w/ hose Clamps 3. Install Y-Fitting and Hose Install a 2” Y-Fitting with 2 pieces of Flexible Hose and Hose Clamps 2 ½” PVC Flexible Hose Sonozaire Roll-Off Container
3. Open the Fire Vent to prevent positive pressure inside the container. Open Fire Vent Sonozaire Roll-Off Container
2” 90 deg Elbow w/ Hose Clamp Complete Sonozaire Install 2” Y Fitting w/ 3 hose Clamps 2 ½” PVC Flexible Hose 2” Flange Sonozaire Loading Chute Roll-Off Container Fire Vent Opened
How is Ozone Manufactured?
Process of Ozone Generation 2. 0 xygen (02) converts to Ozone (03) inside glass cylinders by passing through a high voltage electrical field. 3. Ozone is forced out of the nozzle of the ozone generator and into the garbage container or garbage treatment area. 1. Outside Air (02) enters into the ozone machine through the air filter.
