Web. Sphere Process Server technical overview & demonstration Technology of Information Systems Maurits André Web. Sphere Process Server technical overview & demonstration Technology of Information Systems Maurits André & Marcel Cornelisse Web. Sphere Technical Sales 15 -9 -2009 © IBM Corporation 2009

IBM Nederland B. V. Agenda § SOA BPM Lifecycle § End-to-End demonstration § A IBM Nederland B. V. Agenda § SOA BPM Lifecycle § End-to-End demonstration § A closer look at Web. Sphere Process Server 2 © IBM Corporation 2009

IBM Nederland B. V. Who is IBM? § IBM is the world’s largest IT IBM Nederland B. V. Who is IBM? § IBM is the world’s largest IT company, founded in 1924 § IBM’s business lines – Hardware – Software 2008 Pretax Income Mix – Services – Financing – Research § 2008 Revenue over $100 billion § Number of employees: 386, 558 § IBM University Relations, see: – http: //www-304. ibm. com/jct 09002 c/university/scholars/ur/index. html 3 © IBM Corporation 2009

IBM Nederland B. V. What is Business Process Management? BPM is a discipline combining IBM Nederland B. V. What is Business Process Management? BPM is a discipline combining software capabilities and business expertise through people, systems, and information to accelerate time between process improvements, facilitating business innovation What does BPM with SOA provide? Business Processes BPM with SOA provides process flexibility by improving how you design, manage, and optimize your business processes and reuse existing assets. External Services (Application & Information) Operational Systems Application (Application & Information Assets) Application Content 4 Data Registry © IBM Corporation 2009

IBM Nederland B. V. The SOA Solution Stack – Driven by BPM Services are IBM Nederland B. V. The SOA Solution Stack – Driven by BPM Services are the “building blocks” for business processes SOA improves how you design, manage, and optimize your business processes § Services are building blocks § Reuse of existing assets § Flexibility to change § Utilizes both Technical & Business Services 5 © IBM Corporation 2009

IBM Nederland B. V. SOA – BPM Lifecycle view § Implement Business Processes § IBM Nederland B. V. SOA – BPM Lifecycle view § Implement Business Processes § Compose Services § Build, Construct & Test § Gather requirements § Model & Simulate Business Processes § § § 6 Service Versioning Re-use before build Business/IT alignment Ownership Impact Analysis § Execute and Integrate § People § Process § Information § Applications § Manage applications & services § Monitor business metrics © IBM Corporation 2009

IBM Nederland B. V. SOA – BPM Lifecycle Product Mapping § Web. Sphere Integration IBM Nederland B. V. SOA – BPM Lifecycle Product Mapping § Web. Sphere Integration Developer § Web. Sphere Process Server § Web. Sphere Business Modeler § Web. Sphere Service Registry and Repository 7 § Web. Sphere Business Monitor © IBM Corporation 2009

End to End Demonstration customer case © IBM Corporation 2009 End to End Demonstration customer case © IBM Corporation 2009

IBM Nederland B. V. Company XYZ – background § Real estate company, specialized in IBM Nederland B. V. Company XYZ – background § Real estate company, specialized in development and letting of accommodation and residential concepts in the higher rent sector. § ± 28, 000 houses/apartments, value over € 4 billion § ± 300 employees. IT department ± 20 people. § XYZ was looking for a solution to integrate several siloed backend systems. Business goals: – streamline processes – reduce manual tasks 9 – improve data quality – improve time-to-market © IBM Corporation 2009

IBM Nederland B. V. How do processes work with services Aanbiedings brief Slecteren gegevens IBM Nederland B. V. How do processes work with services Aanbiedings brief Slecteren gegevens kandidaat huurder Selecteren woning Afspraak maken Bijwerken gegevens Versturen Corresponden tie Huur contract Start Afspraak huurder Contract Gegevens wijzigen Definitief contract Einde Business Processes WSDL Enterprise Service Bus e*Gate. TM Adapter Comm. Adapter Integration Backend systems (COTS) Web 10 CRM Housing B 2 B Services © IBM Corporation 2009

IBM Nederland B. V. Process to create lease contract – BPEL 11 © IBM IBM Nederland B. V. Process to create lease contract – BPEL 11 © IBM Corporation 2009

IBM Nederland B. V. 12 © IBM Corporation 2009 IBM Nederland B. V. 12 © IBM Corporation 2009

IBM Nederland B. V. 13 © IBM Corporation 2009 IBM Nederland B. V. 13 © IBM Corporation 2009

IBM Nederland B. V. How did we built it… 14 © IBM Corporation 2009 IBM Nederland B. V. How did we built it… 14 © IBM Corporation 2009

A closer look at Web. Sphere Process Server © IBM Corporation 2009 A closer look at Web. Sphere Process Server © IBM Corporation 2009

IBM Nederland B. V. Requirements for the SOA Build and Run platform § Build IBM Nederland B. V. Requirements for the SOA Build and Run platform § Build new Services – ‘Top Down’ § Integrate existing systems as Services – ‘Bottom Up’ § Service Composition/Aggregation – to enable re-use § Orchestrate Services to implement Business Processes Preferable through a unified programming model! 16 © IBM Corporation 2009

IBM Nederland B. V. Web. Sphere Process Server V 6 Components Service Components Supporting IBM Nederland B. V. Web. Sphere Process Server V 6 Components Service Components Supporting Services SOA Core Business Processes Mediation Flows (ESB) Human Tasks Business State Machines Business Rules Business Interface Object Maps Relation. Maps ships Service Component Architecture Business Objects Dynamic Service Selection Common Event Infrastructure Web. Sphere Application Server ND (J 2 EE Runtime) 17 © IBM Corporation 2009

IBM Nederland B. V. SCA programming model: Assembling the Services … 18 © IBM IBM Nederland B. V. SCA programming model: Assembling the Services … 18 © IBM Corporation 2009

IBM Nederland B. V. Service Component Architecture: the paradigm § Think of what has IBM Nederland B. V. Service Component Architecture: the paradigm § Think of what has taken place in the car and computer industry: – Componentization and standardization which enabled – Assembling from parts and resulted in – Improved time to market, increased flexibility and innovation 19 © IBM Corporation 2009

IBM Nederland B. V. A Basic Service … § Service Provider provides an Interface IBM Nederland B. V. A Basic Service … § Service Provider provides an Interface § Service Caller invokes the Service Provider’s Interface § Logical components: – Interface – Contract for the Service – Reference – Service needed in order to execute 20 © IBM Corporation 2009

IBM Nederland B. V. The Logical Interface … § Service provides an Interface § IBM Nederland B. V. The Logical Interface … § Service provides an Interface § Caller expects to call same Interface 21 © IBM Corporation 2009

IBM Nederland B. V. Processes and Services … § Process invokes Services § Process IBM Nederland B. V. Processes and Services … § Process invokes Services § Process exposes an Interface 22 © IBM Corporation 2009

IBM Nederland B. V. Logical View of Processes and Services … § Process exposes IBM Nederland B. V. Logical View of Processes and Services … § Process exposes an Interface § Process invokes Services § It looks just like any other Service 23 © IBM Corporation 2009

IBM Nederland B. V. Service Component Architecture: Overview Interface: How to call this component IBM Nederland B. V. Service Component Architecture: Overview Interface: How to call this component Interface Reference: What this components calls Declarative QOS: §Security §Communication styles §Transactional behavior Java BPEL State Machine Business Rules Human Task Selector Interface Maps WESB Mediation Implementation Types 24 © IBM Corporation 2009

IBM Nederland B. V. SCA programming model in action Java Application Sell additional services IBM Nederland B. V. SCA programming model in action Java Application Sell additional services based on customer profile Human Task get Approved Human intervention Approved/ suspect on applications to Denied prevent fraud Imported EIS System Call Credit Rating service from an existing application Business State Machine WS-BPEL Business Process Flexibly building business processes based on standards Business Rules Adapting to business events If Approved then Send letter offering gold Enable rapidly changing customer If NOT Approved decision point Send letter offering Credit counseling service 25 © IBM Corporation 2009

IBM Nederland B. V. Composition: Modules, Imports and Exports … ‘Exports’ advertise capability out IBM Nederland B. V. Composition: Modules, Imports and Exports … ‘Exports’ advertise capability out from a module Module ‘Imports’ call capability from external services or modules § Module: Assembly of SCA components § Unit of deployment: J 2 EE EAR file § A (re-usable) Service: Interface with binding and implementation 26 © IBM Corporation 2009

IBM Nederland B. V. Interacting with the outside world § Calling external systems – IBM Nederland B. V. Interacting with the outside world § Calling external systems – Import • Interface + binding: – REST – SCA – Web Service (SOAP/HTTP, SOAP/JMS) – JMS – MQ/JMS – Stateless Session Bean – Outbound Adapters 27 § Exposing to external systems – Export • – – – Interface + binding: REST SCA Web Service (SOAP/HTTP, SOAP/JMS) JMS MQ MQ/JMS – Inbound Adapters © IBM Corporation 2009

IBM Nederland B. V. Adapters…. . integrating existing systems/applications § Adapters acts as a IBM Nederland B. V. Adapters…. . integrating existing systems/applications § Adapters acts as a mediator to the asset – One face looks like a Service (SCA component) – One face looks like a native user SCA 28 © IBM Corporation 2009

IBM Nederland B. V. J 2 C Adapters § All adapters are included in IBM Nederland B. V. J 2 C Adapters § All adapters are included in Web. Sphere Integration Developer – Application Adapters • SAP, Siebel, People. Soft, JD Edwards, Oracle E-Business Suite, – Technology Adapters • Flat File, FTP, JDBC, Email, I/Series, CICS and IMS § Wizard driven configuration • Transforms backend into SCA component with Interface and Business Objects 29 © IBM Corporation 2009

IBM Nederland B. V. SCA: Using Modules for Encapsulation and Reuse § Modules: Encapsulate IBM Nederland B. V. SCA: Using Modules for Encapsulation and Reuse § Modules: Encapsulate and Reuse Functionality § Libraries: Share common definitions Get Customer Status Process: Order do. Order § web service Approve Order Module: Process Order Store Order Module: Approve Order Manually BO: Order IF: Store. Order Library: Order. Lib 30 Human Task: Approve Order Store Order Interface Map Convert to DB 2 Adapter for Relational DB DB 2 Module: Update Order Database © IBM Corporation 2009
